Replacing the subwoofer
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1 Align the screw holes on the subwoofer with the screw holes on the computer
base.
2 Replace the screws that secure the subwoofer to the computer base.
Post-requisites
1 Follow the procedure from step 4 to step 10 in “Replacing the system board”.
2 Replace the display assembly.
3 Replace the I/O board.
4 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
5 Replace the wireless card.
6 Replace the base panel.
46
