Removing the status-light board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base panel.
2 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
Procedure
1 Lift the latch and disconnect the status-light board cable from the status-light
board.
2 Remove the screws that secure the status-light board to the palm-rest
assembly.
3 Lift the status-light board off the palm-rest assembly.
15
Removing the status-light board 42
