Removing the computer base
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base panel.
2 Remove the wireless card.
3 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
4 Remove the display assembly.
5 Remove the power-adapter port.
6 Remove the battery.
7 Remove the speakers.
8 Remove the I/O board.
9 Remove the subwoofer.
Procedure
After performing the prerequisites, we are left with the computer base.
53
Removing the computer base 119
