Removing the I/O board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base panel.
2 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
Procedure
1 Disconnect the subwoofer cable from the I/O board.
2 Lift the latch and disconnect the I/O-board cable from the I/O board.
3 Remove the screws that secure the I/O board to the computer base.
4 Gently tilt and lift to release the I/O ports from the computer base.
5 Lift the I/O board off the computer base.
25
Removing the I/O board 65
