Removing the display assembly
Prerequisites
1 Follow the procedure in Before working inside your computer.
2 Remove the base cover.
3 Remove the rear I/O-cover.
About this task
NOTE: The display assembly is a Hinge-up Display (HUD) and cannot be further disassembled. If components within
the display assembly need to be replaced, the entire display assembly is to be replaced.
The following image indicates the location of the display assembly and provides a visual representation of the removal
procedure.
21
