Dell ECS EX Series User Manual

Table 26. Aggregation port cabling (continued)
55 <-------------> 3
56 <-------------> 4
Fox Port Port Eagle
53 <-------------> 1
54 <-------------> 2
55 <-------------> 3
56 <-------------> 4
Rack 2
Expansion
Hound Port Port Falcon Aggregation
Switches
53 <-------------> 5
54 <-------------> 6
55 <-------------> 7
56 <-------------> 8
Fox Port Port Eagle
53 <-------------> 5
54 <-------------> 6
55 <-------------> 7
56 <-------------> 8
Rack 3
Expansion
Hound Port Port Falcon Aggregation
Switches
53 <-------------> 9
54 <-------------> 10
55 <-------------> 11
56 <-------------> 12
Fox Port Port Eagle
53 <-------------> 9
54 <-------------> 10
55 <-------------> 11
56 <-------------> 12
Rack 4
Expansion
Hound Port Port Falcon Aggregation
Switches
53 <-------------> 13
54 <-------------> 14
55 <-------------> 15
56 <-------------> 16
Fox Port Port Eagle
53 <-------------> 13
54 <-------------> 14
55 <-------------> 15
56 <-------------> 16
Rack 5
Expansion
Hound Port Port Falcon Aggregation
Switches
EXF900 Platform 61
