Table 26. Aggregation port cabling (continued)
53 <-------------> 17
54 <-------------> 18
55 <-------------> 19
56 <-------------> 20
Fox Port Port Eagle
53 <-------------> 17
54 <-------------> 18
55 <-------------> 19
56 <-------------> 20
Rack 6
Expansion
Hound Port Port Falcon Aggregation
Switches
53 <-------------> 21
54 <-------------> 22
55 <-------------> 23
56 <-------------> 24
Fox Port Port Eagle
53 <-------------> 21
54 <-------------> 22
55 <-------------> 23
56 <-------------> 24
Rack 7
Expansion
Hound Port Port Falcon Aggregation
Switches
53 <-------------> 25
54 <-------------> 26
55 <-------------> 27
56 <-------------> 28
Fox Port Port Eagle
53 <-------------> 25
54 <-------------> 26
55 <-------------> 27
56 <-------------> 28
