Dell EMC XC Core XC650 User Manual

Table 18. Supported Intel Persistent Memory 200 series (BPS) for dual processor configurations
Configuration Description per
processor
Memory population rules
RDIMMs or LRDIMMs Intel Persistent Memory 200
series (BPS)
Configuration 1 4 x RDIMMs, 4 x Intel
Persistent Memory 200
series (BPS)
Processor1 {A1, 2, 3, 4}
Processor2 {B1, 2, 3, 4}
Processor1 {A5, 6, 7 ,8}
Processor2 {B5, 6, 7, 8}
Configuration 2 6 x RDIMMs, 1 x Intel
Persistent Memory 200
series (BPS)
Processor1 {A1, 2, 3, 4, 5, 6}
Processor2 {B1, 2, 3, 4, 5, 6}
Processor1 {A7}
Processor2 {B7}
Configuration 3 8 x RDIMMs, 1 x Intel
Persistent Memory 200
series (BPS)
Processor1 {A1, 2, 3, 4, 5, 6, 7, 8}
Processor2 {B1, 2, 3, 4, 5, 6, 7, 8}
Processor1 {A9}
Processor2 {B9}
Configuration 4 8 x RDIMMs, 4 x Intel
Persistent Memory 200
series (BPS)
Processor1 {A1, 2, 3, 4, 5, 6, 7, 8}
Processor2 {B1, 2, 3, 4, 5, 6, 7, 8}
Processor1 {A9, 10, 11, 12}
Processor2 {B9, 10, 11, 12}
Configuration 5 8 x RDIMMs, 8 x Intel
Persistent Memory 200
series (BPS)
Processor1 {A1, 2, 3, 4, 5, 6, 7, 8}
Processor2 {B1, 2, 3, 4, 5, 6, 7, 8}
Processor1 {A9, 10, 11, 12, 13, 14, 15,
16}
Processor2 {B9, 10, 11, 12, 13, 14, 15,
16}
Configuration 6 12 x RDIMMs, 2 x Intel
Persistent Memory 200
series (BPS)
Processor1 {A1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 15, 16}
Processor2 {B1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 15, 16}
Processor1 {A5, 6}
Processor2 {B5, 6}
NOTE: There are limited configurations available for dual socket servers with only one processor populated.
Table 19. Intel Persistent Memory 200 series (BPS) Configuration 1 - 4 x RDIMMs/ LRDIMMs, 4 x Intel
Persistent Memory 200 series (BPS) per processor
Total No of
RDIMMs/
LRDIMMs
Total No of
Intel Persistent
Memory 200
series (BPS)
DIMMs
1 R/LRDIMM
capacity (GB)
1 Intel
Persistent
Memory 200
series (BPS)
capacity (GB)
Total Standard
Memory Capacity
(GB)
Total PM
Capacity
(GB)
Supported
Modes
4 4 16 128 64 512 MM or AD
4 4 32 128 128 512 MM or AD
4 4 64 128 256 512 AD
4 4 128 128 512 512 AD
4 4 16 256 64 1024 MM or AD
4 4 32 256 128 1024 MM or AD
4 4 64 256 256 1024 MM or AD
4 4 128 256 512 1024 AD
4 4 256 256 1024 1024 AD
4 4 16 512 64 2048 AD
4 4 32 512 128 2048 MM or AD
4 4 64 512 256 2048 MM or AD
Installing and removing system components 55
