Table 19. Intel Persistent Memory 200 series (BPS) Configuration 1 - 4 x RDIMMs/ LRDIMMs, 4 x Intel
Persistent Memory 200 series (BPS) per processor (continued)
Total No of
RDIMMs/
LRDIMMs
Total No of
Intel Persistent
Memory 200
series (BPS)
DIMMs
1 R/LRDIMM
capacity (GB)
1 Intel
Persistent
Memory 200
series (BPS)
capacity (GB)
Total Standard
Memory Capacity
(GB)
Total PM
Capacity
(GB)
Supported
Modes
4 4 128 512 512 2048 MM or AD
Table 20. Intel Persistent Memory 200 series (BPS) Configuration 2 - 6 x RDIMMs/ LRDIMMs, 1 x Intel
Persistent Memory 200 series (BPS) per processor
Total No of
RDIMMs/
LRDIMMs
Total No of
Intel
Persistent
Memory 200
series (BPS)
DIMMs
1 R/LRDIMM
capacity (GB)
1 Intel
Persistent
Memory 200
series (BPS)
capacity (GB)
Total Standard
Memory Capacity
(GB)
Total PM
Capacity
(GB)
Supported Modes
6 1 16 128 96 128 AD
6 1 32 128 192 128 AD
6 1 64 128 384 128 AD
6 1 128 128 768 128 AD
6 1 16 256 96 256 AD
6 1 32 256 192 256 AD
6 1 64 256 384 256 AD
6 1 128 256 768 256 AD
6 1 256 256 1536 256 AD
6 1 16 512 96 512 AD
6 1 32 512 192 512 AD
6 1 64 512 384 512 AD
6 1 128 512 768 512 AD
Table 21. Intel Persistent Memory 200 series (BPS) Configuration 3 - 8 x RDIMMs/ LRDIMMs, 1 x Intel
Persistent Memory 200 series (BPS) per processor
Total No of
RDIMMs /
LRDIMMs
Total No of
Intel
Persistent
Memory 200
series (BPS)
DIMMs
1 R/LRDIMM
capacity (GB)
1 Intel
Persistent
Memory 200
series (BPS)
capacity (GB)
Total Standard
Memory Capacity
(GB)
Total PM
Capacity
(GB)
Supported Modes
8 1 16 128 128 128 AD
8 1 32 128 256 128 AD
8 1 64 128 512 128 AD
8 1 128 128 1024 128 AD
8 1 16 256 128 256 AD
8 1 32 256 256 256 AD
8 1 64 256 512 256 AD
8 1 128 256 1024 256 AD
8 1 256 256 2048 256 AD
