Dell OptiPlex Small Form Factor Plus 7020 User Manual

Table 6. Memory matrix(continued)
Configurati
on
Slot
16 GB DDR5 8 GB 8 GB
32 GB DDR5 32 GB
32 GB DDR5 16 GB 16 GB
32 GB DDR5 8 GB 8 GB 8 GB 8 GB
64 GB DDR5 32 GB 32 GB
64 GB DDR5 16 GB 16 GB 16 GB 16 GB
128 GB
DDR5
32 GB 32 GB 32 GB 32 GB
External ports
The following table lists the external ports of your OptiPlex Small Form Factor Plus 7020.
Table 7. External ports
Description Values
Network port
One RJ-45 port 10/100/100 Mbps
USB ports
● One USB 2.0 (480 Mbps) port
● One USB 2.0 (480 Mbps) with PowerShare port
● Two USB 2.0 (480 Mbps) with SmartPower On ports
● Three USB 3.2 Gen 1(5 Gbps) ports
● Two USB 3.2 Gen 2 (10 Gbps) port
● One USB 3.2 Gen 2x2 Type-C (20 Gbps) port
NOTE: This port does not support video/audio
streaming.
Audio port
● One Universal audio port
● One Re-tasking line-out/line-in audio port
Video port
● One optional port (HDMI 2.1/DisplayPort 1.4a (HBR3
support)/VGA/USB 3.2 Gen 2 (10 Gbps) Type-C port with
DisplayPort)
NOTE: The maximum resolution supported by optional
port is
○ HDMI 2.1 port: Up to 4096 x 2160 @60Hz.
○ DisplayPort 1.4a (HBR3 support) port: Up to
5120 x 3200 @60Hz.
○ VGA port: Up to 1920 x 1200 @60Hz.
○ USB 3.2 Gen 2 (10 Gbps) Type-C port with
DisplayPort: Up to 5120 x 3200 @60Hz.
● Three DisplayPort 1.4a (HBR2 support) ports
NOTE: The maximum resolution that is supported is up
to 4096 x 2304 @60Hz.
Media-card reader
One SD-card 4.0 slot (optional)
Power-adapter port
Not supported
Security-cable slot
● Security-cable slot (for Kensington locks)
Specifications of OptiPlex Small Form Factor Plus 7020 21
