Removing and installing side cover
Removing the side cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The following images indicate the location of the side cover and provide a visual representation of the removal procedure.
Figure 3. Removing the side cover
Steps
1. Slide the release latch until your hear a click and slide the side cover towards the back of the computer.
2. Lift the side cover from the chassis.
Installing the side cover
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the side cover and provide a visual representation of the installation procedure.
5
38 Removing and installing side cover
