Dell OptiPlex Small Form Factor Plus 7020 User Manual

Table 10. Wireless module specifications(continued)
Description Option one Option two
● Wi-Fi 6E (WiFi 802.11ax) ● Wi-Fi 6 (WiFi 802.11ax)
Encryption
● 64-bit/128-bit WEP
● AES-CCMP
● TKIP
● 64-bit/128-bit WEP
● AES-CCMP
● TKIP
Bluetooth wireless card
Bluetooth 5.3 Bluetooth 5.3
NOTE: The version of the Bluetooth wireless card may vary depending on the
operating system that is installed on your computer.
Audio
The following table lists the audio specifications of your OptiPlex Small Form Factor Plus 7020.
Table 11. Audio specifications
Description Values
Audio type
High Definition Audio
Audio controller
Realtek ALC3246-CG
Internal audio interface
High Definition Audio (HDA)
External audio interface
● One universal audio port
● One retaskable line-in/line-out audio port
Storage
This section lists the storage options on your OptiPlex Small Form Factor Plus 7020.
Table 12.
Storage specifications
Storage type Interface type Capacity
3.5-inch hard-disk drive, 7200 RPM SATA 3.0 Up to 2 TB
3.5-inch hard-disk drive, 5400 RPM SATA 3.0 4 TB
M.2 2230 solid-state drive, Class 25 PCIe NVMe, up to 64 Gbps Up to 2 TB
M.2 2230 solid-state drive, Class 35 PCIe NVMe, up to 64 Gbps Up to 1 TB
M.2 2230 solid-state drive, Class 35,
Self-Encrypting drive
PCIe NVMe, up to 64 Gbps 256 GB
M.2 2280 solid-state drive, Class 40 PCIe NVMe, up to 64 Gbps Up to 2 TB
M.2 2280 solid-state drive, Class 40,
Self-Encrypting drive
PCIe NVMe, up to 64 Gbps Up to 1 TB
Specifications of OptiPlex Small Form Factor Plus 7020 23
