Table 15. Power ratings(continued)
Description Option one Option two
Rated output voltage
● +12 VA
● +12 VB
● +12 VA
● +12 VB
Temperature range
Operating
5°C to 45°C (41°F to 113°F) 5°C to 45°C (41°F to 113°F)
Storage
-40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
Power supply connector
The following table lists the Power supply connector specifications of your OptiPlex Small Form Factor Plus 7020.
Table 16. Power supply connector
Power supply unit Connectors
260 W internal power supply unit
(PSU), 85% Efficient, 80 Plus
Bronze
● Two 4 pin connectors for processor
● One 8 pin connector for system board
300 W internal power supply unit
(PSU), 92% Efficient, 80 Plus
Platinum
● Two 4 pin connectors for processor
● One 8 pin connector for system board
GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your OptiPlex Small
Form Factor Plus 7020.
Table 17.
GPU—Integrated
Controller External display support Memory size Processor
Intel UHD Graphics 730
● Three DisplayPort 1.4a
(HBR2 support) ports
● One video port (HDMI
2.1/Displayport 1.4a
(HBR3)/VGA/USB Type-
C port with DisplayPort Alt
mode)(optional)
Shared system memory 14th Generation Intel Core
i3-14100
Intel UHD Graphics 770
● Three DisplayPort 1.4a
● One video port (HDMI
2.1/Displayport 1.4a
(HBR3)/VGA/USB Type-
C port with DisplayPort Alt
mode)(optional)
Shared system memory 14th Generation Intel Core
i5-14500 vPro, i5-14600
vPro, i7-14700 vPro,
i9-14900 vPro processors
26 Specifications of OptiPlex Small Form Factor Plus 7020
