5. Install the 3.5-inch hard drive, if applicable.
6. Install the front bezel.
7. Install the side cover.
8. Follow the procedure in After working inside your computer.
Power-supply unit
Removing the power-supply unit
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the 3.5-inch hard drive, if applicable.
5. Remove the disk-drive cage.
About this task
The following images indicate the location of the power-supply unit and provide a visual representation of the removal
procedure.
90
Removing and installing Field Replaceable Units (FRUs)
