Dell OptiPlex Small Form Factor Plus 7020 User Manual

Optical drive
Removing the optical drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the 3.5-inch hard drive, if applicable.
5. Remove the disk-drive cage.
About this task
NOTE: The optical drive is located within the disk-drive cage. Follow the below-mentioned procedure on the disk-drive
cage to remove or install the optical drive.
The following images indicate the location of the optical-drive assembly and provide a visual representation of the removal
procedure.
Figure 13. Removing the optical drive
Steps
1. Push the tab on the optical drive to release the optical drive from the disk-drive cage.
Removing and installing Customer Replaceable Units (CRUs)
51
