116 Dell PowerConnect 55xx Systems User Guide
– Shutdown — Drops packet that meet the ACL criteria, and disables
the port to which the packet was addressed.
–
Logging of Dropped Packets — Check to activate logging of dropped
packets.
Configuring IP-based ACEs Using CLI Commands
The following table summarizes the CLI commands for configuring I
P-based
ACLs
.
Table 8-7. IP-Based ACE CLI Commands
CLI Command Description
permit protocol {any|{source-prefix/length
}{any|destination- prefix/length } [dscp
number|precedence number] [time-range
time-range-name]
permit icmp {any|{source-prefix/length
}{any|destination-prefix/length }
{any|icmp-type}{any|icmp-code} [dscp
number|precedence number] [time-range
time-range-name]
permit tcp {any|{source-prefix/length }
{any|source-port/port-range}
}{any|destination prefix/length }
{any|destination-port/port-range} [dscp
number|precedence number] [match-all list-
of-
flags] [time-range time-range-name]
permit udp {any|{source-prefix/length }}
{any|source-port|port-range}
}{any|destination prefix/length }
{any|destination-port/port-range} [dscp
number|precedence number] [time-range
time-range-name]
Sets permit conditions
for IPv6 access list.
