Dell PowerConnect 55xx Systems User Guide 355
– Active Image — The name of the image file that is currently active on
the unit in the stack.
–
After Reset — The image file that will be active on the unit in the
stack after the device is reset. The possible options are:
•
Image 1 — Activates Image file 1 after the device is reset.
•
Image 2 — Activates Image file 2 after the device is reset.
2
Click Apply to select the image file to be used after reset in After Reset .
Working with the Active Image File Using CLI Commands
The following table summarizes the CLI commands for viewing fields
displayed in the Active Images
.
The following is an example of the CLI commands:
Copy Files
Firmware and configuration files can be copied between units in the stack.
Use the Copy Files page to perform the following:
• Copy the firmware on the Master unit to another unit in the stack.
• Copy the master Running Configuration file to the master sTartup
Configuration file, or copy the configuration to a user-defined
configuration file.
• Copy the master Startup Configuration file to a backup file on the Flash
file system or to a USB if available.
Table 9-66. Active Image CLI Commands
CLI Command Description
boot system {image-
1|image-2} [switch
number|all]
Sets the system image that the device loads at
startup.
show version [unit
unit]
Displays version information for the system
console# boot system image-1 all
