454 Dell PowerConnect 55xx Systems User Guide
MSTP Instance Settings
To configure MSTP instances:
1
Click
Switching
>
Spanning Tree
>
MSTP Instance Settings
in the tree
view to display the
MSTP Instance Settings
page
.
Figure 13-7. MSTP Instance Settings
The MSTP instances and their associated VLANs are displayed.
2
Select an
Instance ID
.
3
Enter the
Bridge Priority
(0-61440)
of this bridge for the selected MSTP
instance.
4
The following fields are displayed:
–
Included VLANs
— Displays VLANs included in this instance.
–
Designated Root Bridge ID
— Priority and MAC address of the Root
Bridge for the MST instance.
