Dell PowerConnect 55xx Systems User Guide 489
–
Associate Primary VLAN
— If the Private VLAN type is Isolated,
check to associate the isolated VLAN with a primary VLAN, thus
allowing traffic between isolated and promiscuous ports.
–
Primary VLAN ID
— Select a VLAN to be associated with the
isolated VLAN.
4
To assign ports to the private VLAN, click
Membership
.
5
Select a Primary VLAN ID.
6
Select a Isolated VLAN ID.
7
Select the ports to be assigned to each VLAN, and assign each port/LAG a
port type in the Admin row of ports/LAGs. The possible options are:
–
H - Host (Isolated)
— Port is isolated.
–
P - Promiscuous
— Port is promiscuous.
–
C - Conditional (operational state depends on Port VLAN Mode)
—
Port receives the Port VLAN type set in the
VLAN Port Settings
page.
See "Port Modes" on page 462 for a description of the various port modes.
Configuring Private VLAN Using CLI Commands
The following table summarizes the CLI commands for configuring private
VLANs.
Table 14-6. Private VLAN CLI Commands
CLI Command Description
private-vlan
{primary|isolated}
no private-vlan
Configures a private VLAN.
Use the no form of this command to
return the VLAN to normal VLAN
configuration.
private-vlan association
[add|remove] secondary-vlan-
list
no private-vlan association
Configures the association between the
primary VLAN and the secondary
VLANs.
Use the no form of this command to
remove the association.
