Dell PowerEdge C6220 - Removing a 2.5-Inch Hard-Drive Blank; Installing a 2.5-Inch Hard-Drive Blank

134 | Installing System Components
Removing a 2.5-inch Hard-Drive Blank
CAUTION: To maintain proper system cooling, all empty hard-drive bays must
have drive blanks installed.
NOTE: This section is applicable to systems with hot-swappable hard drives only.
1 Pull the handle to remove the 2.5-inch hard-drive blank out of the
hard-drive bay. See Figure 3-4.
Figure 3-4. Removing or Installing a 2.5-inch Hard-Drive Blank
1
2.5-inch hard-drive blank
2
handle
3
latch
Installing a 2.5-inch Hard-Drive Blank
1 With the latch side facing up, slide the latch into the hard-drive bay
first.
2 Push the 2.5-inch hard-drive with a slight inclination into the hard-
drive bay until the hard-drive blank is seated in place. See Figure 3-4.
