Installing System Components | 171
Removing the LSI 9265-8i Card for 2U Node
NOTE: The LSI 9265-8i card assembly should include the BBU interposer card
which is connected to the LSI 9265-8i RAID battery. The illustrations in this section
are just for your removal and installation reference. For more information of the
LSI 9265-8i RAID battery, see “LSI 9265-8i RAID Battery” on page 180.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
NOTE: The LSI 9265-8i card can be supported only on the 1.5U riser card. For the
information of the riser card, see “Removing the Riser card for 2U Node” on page
188.
1 Remove the system-board assembly. See “Removing a System-Board
Assembly" on page 142.
2 Disconnect the two SAS/SGPIO cables connecting to the LSI 9265-8i
card assembly.
