24 | About Your System
Back Panel Features and Indicators
Figure 1-18 Back Panel with Four System Boards
Figure 1-19 Back Panel with Two System Boards
Item
Indicator, Button
Or Connector
Icon
Description
1
Power supply 2
1200 W/1400 W
2
Power supply 1
1200 W/1400 W
3
USB ports (2)
Connect USB devices to the
system. The ports are USB 2.0-
compliant.
