Dell PowerEdge C6220 - Page 137

Installing System Components | 137
CAUTION: When installing a hard-drive carrier, ensure that the adjacent drives are
fully installed. Inserting a hard-drive carrier and attempting to lock its handle next
to a partially installed carrier can damage the partially installed carrier's shield
spring and make it unusable.
CAUTION: To prevent data loss, ensure that your operating system
supports hot-swappable drive installation. See the documentation supplied with
the operating system.
1 Remove the four screws. See Figure 3-6.
2 Lift the hard drive out of the hard-drive carrier.
Figure 3-6. Removing and Installing a Hard Drive from the Hard-Drive Carrier
1
hard drive
2
screw (4)
3
hard-drive carrier
