1. Base cover 2. Battery
3. Heat sink 4. Right fan
5. System board 6. Audio jack
7. Speakers 8. Palm-rest and keyboard assembly
9. WLAN antennas 10. Display assembly
11. Touchpad flat printed cable 12. Solid-state drive
13. SSD thermal plate 14. Left fan
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
