Dell Precision 5490 - Installing the M.2 2230 Solid-State Drive

4. Remove the screw (M2x2) that secures the M.2 2230 solid state drive to the M.2 2230 solid state drive bracket.
5. Lift to remove M.2 2230 solid state drive from the M.2 2230 solid state drive bracket.
Installing the M.2 2230 solid-state drive
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
NOTE: For computers shipped with M.2 2230 solid-state drive.
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the M.2 2230 solid-state drive and provides a visual representation of the installation
procedure.
Removing and installing Field Replaceable Units (FRUs) 51
