4. Remove the six screws (M2.5x5) that secure the display hinges to the palm-rest and keyboard assembly.
5. Slide the bottom assembly slightly to the left and then move it away from the display assembly.
NOTE:
The display assembly is a Hinge-Up Design (HUD) assembly and cannot be further disassembled once it is
removed from the bottom chassis. If any components in the display assembly are malfunctioning, then you must replace
the entire display assembly.
Installing the display assembly
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the display assembly and provides a visual representation of the installation procedure.
76
Removing and installing Field Replaceable Units (FRUs)
