Figure 43. Removing the graphics-card fan
Steps
1. Align the screw holes on the graphics-card fan with the screw holes on the palm-rest and keyboard assembly.
2. Replace the two screws (M2x4) that secure the graphics-card fan to the palm-rest and keyboard assembly.
3. Connect the graphics-card fan cable to the connector on the system board.
4. Adhere the tweeter speaker in its compartment on the palm-rest and keyboard assembly.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Heat sink
Removing the heat sink for integrated graphics
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
Removing and installing Field Replaceable Units (FRUs)
61
