Steps
1 Place the heat sink on the system board and align the screw holes on the heat sink with the screw holes on the system board.
2 In sequential order (as indicated on the heat sink), tighten the seven captive screws that secure the heat sink to the system board.
Next step
1 Install the CPU fan.
2 Install the GPU fan.
3 Install the battery.
4 Install the base cover.
5 Follow the procedure in After working inside your computer.
Coin-cell battery
Removing the coin-cell battery
Prerequisites
1 Follow the procedure in Before working inside your computer.
2 Remove the base cover.
3 Remove the battery.
NOTE
: Removing the coin-cell battery resets the BIOS setup program's settings to default. It is recommended that you note the
BIOS setup program's settings before removing the coin-cell battery.
About this task
The gure indicates the location of the coin-cell battery and provides a visual representation of the removal procedure.
Disassembly and reassembly
41
