eZFC-424R4-24 Application Guide
Edition 2.6
Page 45 of 84
1. On the LINKnet I/O tab, in the Button Options section, next to the button number that you
want to program, select one of the following functions that you want to assign to that button:
Function Select this option if you want to:
NotUsed_ Designate custom button behavior using GCL or if you want a
blank button.
EcoModeToggle_ Turns on the occupancy eco mode. In eco mode, the setpoints
are widened.
OccupancyOff_ Turn on the standby occupancy mode.
In the additional settings, in the PushButtonOvrdTime field, you
can enter how long the button override should last.
OccupancyOn_ Turn on the occupied mode.
In the additional settings, in the PushButtonOvrdTime field, you
can enter how long the button override should last.
OccupancyToggle_ Toggle between standby and occupied modes during scheduled
occupancy periods.
When pushed during unoccupied mode it starts an occupancy
override timer. When an override has been activated, pushing
the button again will cancel the override and reset the override
timer back to zero.
In the additional settings, in the PushButtonOvrdTime field, you
can enter how long the button override should last.
TempUnitsToggle_ Toggle between displaying the temperature in Celsius and the
temperature in Fahrenheit.
TempDown_ Decrease the temperature setpoint by 0.5 degrees with each
buttonpress. The 0.5 degree amount cannot be changed in the
enteliZONE configurable controller model. In the programmable
controller model, this setting can be overridden using GCL.
In the additional settings, in the OccSetpointOffsetReset field,
you can turn on the Occupancy Setpoint Offset Reset function*.
