LINKnet I/O Tab
Page 46 of 84 eZFC-424R4-24 Application Guide
Edition 2.6
Function Select this option if you want to:
TempUp_ Increase the temperature setpoint by 0.5 degrees with each
buttonpress. The 0.5 degree amount cannot be changed in the
enteliZONE configurable controller model. In the programmable
controller model, this setting can be overridden using GCL.
In the additional settings, in the OccSetpointOffsetReset field,
you can turn on the Occupancy Setpoint Offset Reset function*.
TempSelect_ Set up the button to display the current temperature and setpoint
(if enabled). This button is usually used to switch to temperature
display mode from fan mode.
In the additional settings, in the OccSetpointOffsetReset field,
you can turn on the Occupancy Setpoint Offset Reset function*.
FanDown_ Decrease the displayed fan speed or toggle through fan stages
after FanCycle is pressed. With analog fans, fan speed will
change by this amount = (FanMaxSpeed – FanMinSpeed) / 6.
FanUp_ Increase the displayed fan speed or toggle through fan stages
after FanCycle is pressed. With analog fans, fan speed will
change by this amount = (FanMaxSpeed – FanMinSpeed) / 6.
FanCycle_ Set up the button to display the current fan stage. When the up
and down buttons are not available, toggle this button to select a
fan speed.
FanSelect_ Toggle between automatic and manual fan control. Can be used
together with the slider to manually change the fan speed.
Info_ Toggles between all built-in and input sensor measurements that
the eZNS is reading.
* Occupancy Setpoint Offset Range resets the occupancy setpoint offset at the start of a new
occupancy period.
2. In the Slider field, select a function that you want to assign to the slider:
