Delta AH500 Programming Manual

AH500 Programming Manual
1-4
Classification
Model Name
Description
port, one built-in RS-485/RS-232 port, one built-in USB
port, and one built-in SD interface. It supports 65536
inputs/outputs. The program capacity is 1M steps.
Main
backplane
AHBP04M1-5A
Four-slot main backplane for a CPU/RTU rack
AHBP06M1-5A
Six-slot main backplane for a CPU/RTU rack
AHBP08M1-5A
Eight-slot main backplane for a CPU/RTU rack
AHBP12M1-5A
Twelve-slot main backplane for a CPU/RTU rack
Redundant
backplane
AHBP04MR1-5A Four-slot redundant backplane for a CPU/RTU rack
Extension
backplane
AHBP06E1-5A
Six-slot extension backplane for a CPU/RTU extension
rack
AHBP08E1-5A
Eight-slot extension backplane for a CPU/RTU extension
rack
Redundant
extension
backplane
AHBP06ER1-5A
Six-slot extension backplane with power redundancy for a
CPU/RTU redundant extension rack
AHBP08ER1-5A
Eight-slot extension backplane with power redundancy for
a CPU/RTU redundant extension rack
Digital
input/output
module
AH16AM10N-5A
24 V DC
5 mA
16 inputs
Terminal block
AH32AM10N-5A
24 V DC
5 mA
32 inputs
Terminal block
AH32AM10N-5B
24 V DC
5 mA
32 inputs
DB37 connector
AH32AM10N-5C
24 V DC
5 mA
32 inputs
Latch connector
AH64AM10N-5C
24 V DC
3.2 mA
64 inputs
Latch connector
AH16AM30N-5A
100~240 V AC
4.5 mA~9 mA (100 V, 50 Hz)
16 inputs
Terminal block
AH16AR10N-5A
24 V DC
5 mA
16 inputs
Terminal block
(I/O interrupts are supported.)
AH16AN01R-5A
240 V AC/24 V DC
2 A
16 outputs
Relay
Terminal block
AH16AN01T-5A
12~24 V DC
0.5 A
16 outputs
Sinking output
