AH500 Programming Manual
3-2
3.1 Instructions
Instructions used in the AH500 series PLC include basic instructions and applied instructions.
3.1.1 Basic Instructions
Classification
Description
Contact instructions
Loading the contact, connecting the contact in series, connecting
the contact in parallel, and etc.
Connection instructions
Storing and reading the operation result
Output instructions
Bit device output; pulse output
Master control
Instructions
Setting and resetting the master control
Rising-edge/Falling-edge
detection contact
instructions
Triggering the instructions that load the contact, connect the
contacts in series, and connect the contacts in parallel
Rising-edge/Falling-edge
output instructions
Bit device output
Other instructions
Other instructions
3.1.2 Applied Instructions
API
Classification
Description
0000~0065
Comparison instructions
Comparisons such as =, <>, >, >=, <, <=, and etc.
0100~0118 Arithmetic instructions
Using binary numbers or binary-coded decimal
numbers to add, subtract, multiply, or divide.
0200~0219
Data conversion
instructions
Converting the binary-coded decimal number into
the binary number, and converting the binary
number into the binary-coded decimal number
0300~0310
Data transfer instructions
Transfer the specified data
0400~0402
Jump instructions
The program jumps.
0500~0502
Program execution
instructions
Enabling or disabling the interrupt
0600
I/O refreshing instructions
Refreshing the I/O.
0700~0708
Miscellaneous
instructions
Instructions which are applied to the counters, the
teach mode timers, the special timers, and etc.
0800~0817 Logic instructions
Logical operations such as logical addition, logical
multiplication, and etc.
0900~0904
Rotation instructions
Rotating/Shifting the specified data
1000~1004
Timer and counter
instructions
Timer instructions and counter instructions
1100~1115
Shift instructions
Shifting the specified data
1200~1223
Data processing
instructions
16-bit data processing such as decoding and
encoding.
1300~1302
Structure creation
instructions
Nested loops
1400~1401 Module instructions
Reading the data from the special module and
writing the data into the special module
1500~1524
Floating-point number
instructions
Floating-point number operations
1600~1606
Real-time clock
instructions
Reading/Writing, adding/subtracting and comparing
the time
1700~1704
Peripheral instructions
I/O points connected to the peripheral
1800~1812
Communication
instructions
Controlling the peripheral though communication
1900~1905
Other instructions
Instructions which are different from those
