AH500 Programming Manual
6-260
6.13 Data Processing Instructions
6.13.1 List of Data Processing Instructions
API
Instruction code
Pulse
instruction
Function Step
16-bit
32-bit
1200
SER
DSER

Searching the data
9
1201
SUM
DSUM

Number of bits whose states are ON
5
1202
DECO
–

Decoder
7
1203
ENCO
–

Encoder
7
1204
SEGD
–

Seven-segment decoding
5
1205
SORT
DSORT
–
Sorting the data
11
1206
ZRST
–

Resetting the zone
5
1207
BON
DBON

Checking the state of the bit
7
1208
MEAN
DMEAN

Mean
7
1209
CCD
–

Sum check
7
1210
ABS DABS

Absolute value 3
1211
MINV
–

Inverting the matrix bits
7
1212
MBRD
–

Reading the matrix bit
7
1213
MBWR
–

Writing the matrix bit
7
1214
MBC
–

Counting the bits with the value 0 or 1
7
1215
DIS
–

Disuniting the 16-bit data
7
1216
UNI
–

Uniting the 16-bit data
7
1217
WSUM
DWSUM

Getting the sum
7
1218
BSET
–

Setting the bit in the word device to ON
5
1219
BRST
–

Resetting the bit in the word device
5
1220
BKRST
–

Resetting the specified zone
5
1221
LIMIT
DLIMIT

Confining the value within the bounds
9
1222
BAND
DBAND

Deadband control
9
1223
ZONE
DZONE

Controlling the zone
9
