Instruction code Operand Function
OUT
S
Driving the coil
Device
DX DY X Y M SM S T C HC D L PR
S
●
●
●
●
●
●
●
●
●
●
●
●
Symbol:
S
：
Specified device Bit
Explanation:
1. The logical operation result prior to the application of the instruction OUT is output into the
specified device.
2. The action of the coil contact:
Operation
result
OUT
Coil
Contact
Contact A
(normally open)
Contact B
(normally closed)
False
OFF
OFF
ON
True
ON
ON
OFF
Example:
1. Contact B of X0.0 is loaded, contact A of X0.1 is connected in series, and the coil Y0.0 is
driven.
2. When X0.0 is OFF, and X0.1 is ON, Y0.0 is ON.
