Delta AH500 - 10.1 Introduction

Chapter 6 Applied Instructions
6-197
API Instruction code
運算元
Function
0802
W
D
OR P
S
1
, S
2
, D
Logical OR operation
Device
X Y M S T C HC D L SM SR E PR K 16# “$” DF
S
1
           
S
2
           
D
         
Pulse instruction
16-bit instruction (7 steps)
32-bit instruction (7 steps)
AH500
AH500
AH500
Symbol:
S
1
：
Data source 1 Word/Double word
S
2
：
Data source 2 Word/Double word
D
：
Operation result Word/Double word
Explanation:
1. The logical operator OR takes the binary representations in S
1
and S
2
, and performs the logical
inclusive OR operation on each pair of corresponding bits. The operation result is stored in D.
2. Only the instruction DOR can use the 32-bit counter.
3. The result in each position is 1 if the first bit is 1, the second bit is 1, or both bits are 1.
Otherwise, the result is 0.
Example 1:
When X0.0 is ON, the logical operator OR takes the data in the 16-bit device Y0 and the 16-bit
device Y2, and performs the logical inclusive OR operation on each pair of corresponding bits. The
operation result is stored in Y4.
Before the instruction
is executed
After the instruction
is executed
011 0 1 0 1 0 1 0 1
0 1 0 1
0 1
0 0 0 0 1 1 1 1 1 0
1 0 0 1
0 1
b0
b15
Y0
Y2
S1
S2
Y4
0 1 0 1 1 1 1 1 1 1
1 1 0 1
0 1
b0
b15
D
