AH500 Programming Manual
6-294
D0
D1
D2
D10
338
100
113
125
(D0+D1+D2)
D10
After the instruction
is executed
Additional remark:
1. If n used in the 16-bit instruction is less than 1 or larger than 256, the instruction is not
executed, SM0 is ON, and the error code in SR0 is 16#200B.
2. If n used in the 32-bit instruction is less than 1 or larger than 128, the instruction is not
executed, SM0 is ON, and the error code in SR0 is 16#200B.
3. If S+n-1 or D exceeds the device range, the instruction is not executed, SM0 is ON, and the
error code in SR0 is 16#2003.
