Chapter 6 Applied Instructions
6-375
Additional remark:
1. If S
1
+2, S
2
+2, S+2, or D+2 exceeds the device range, the instruction is not executed, SM0 is ON,
and the error code in SR0 is 16#2003.
2. If the values in S
1
, S
2
, and S exceed the range, the operation error occurs, the instruction is not
executed, SM0 is ON, and the error code in SR0 is 16#2003
3. If users declare the operand S
1
in ISPSoft, the data type will be ARRAY [3] of WORD/INT.
4. If users declare the operand S
2
in ISPSoft, the data type will be ARRAY [3] of WORD/INT.
5. If users declare the operand S in ISPSoft, the data type will be ARRAY [3] of WORD/INT.
6. If users declare the operand D in ISPSoft, the data type will be ARRAY [3] of WORD/INT.
