Delta AH500 - Page 56

Chapter 2 Devices
2-37
SM Function
CPU5X0-RS2
CPU5X0-EN
CPU5X1-RS2
CPU5X1-EN
CPU560-EN2
OFF

ON
STOP

RUN
RUN

STOP
Attribute
Default
*SM2018
The data is sent by using the instruction
EMDRW 4.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2019
The PLC waits for the data after the instruction
EMDRW 4 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2020
The data is received by using the instruction
EMDRW 4.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2021
An error occurs when the instruction EMDRW 4
is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2022
There is a timeout after the instruction EMDRW
4 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2023
The connection is closed after the instruction
EMDRW 4 is used.
× ○ × ○ ○ ON ON ON R ON
*SM2024
The data is sent by using the instruction
EMDRW 5.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2025
The PLC waits for the data after the instruction
EMDRW 5 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2026
The data is received by using the instruction
EMDRW 5.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2027
An error occurs when the instruction EMDRW 5
is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2028
There is a timeout after the instruction EMDRW
5 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2029
The connection is closed after the instruction
EMDRW 5 is used.
× ○ × ○ ○ ON ON ON R ON
*SM2030
The data is sent by using the instruction
EMDRW 6.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2031
The PLC waits for the data after the instruction
EMDRW 6 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2032
The data is received by using the instruction
EMDRW 6.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2033
An error occurs when the instruction EMDRW 6
is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2034
There is a timeout after the instruction EMDRW
6 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2035
The connection is closed after the instruction
EMDRW 6 is used.
× ○ × ○ ○ ON ON ON R ON
*SM2036
The data is sent by using the instruction
EMDRW 7.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2037
The PLC waits for the data after the instruction
EMDRW 7 is use.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2038
The data is received by using the instruction
EMDRW 7.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2039
An error occurs when the instruction EMDRW 7
is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2040
There is a timeout after the instruction EMDRW
7 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2041
The connection is closed after the instruction
EMDRW 7 is used.
× ○ × ○ ○ ON ON ON R ON
*SM2042
The data is sent by using the instruction
EMDRW 8.
× ○ × ○ ○ OFF OFF OFF R/W OFF
*SM2043
The PLC waits for the data after the instruction
EMDRW 8 is used.
× ○ × ○ ○ OFF OFF OFF R OFF
*SM2044
The data is received by using the instruction
EMDRW 8.
× ○ × ○ ○ OFF OFF OFF R/W OFF
