Chapter 6 Applied Instruction
6-399
API
Instruction code Operand Function
1802 REV
S
1
, S
2
, n
The AC motor drive runs counterclockwise.
Device
X Y M S T C HC D L SM SR E PR K 16# “$”
DF
Pulse instruction
16-bit instruction (7 steps)
32-bit instruction
Symbol:
S
1
：
Unit address Word
S
2
：
Operation frequency of the AC motor drives Word
n
：
Mode Word
