AH500 Programming Manual
6-486
API Instruction code Operand
Function
2116 $RPLC P
S
1
, S
2
, S
3
, S
4
, D
Replacing the characters in the string
Device
X Y M S T C HC D L SM SR E PR K 16# “$” DF
S
1
        
S
2
         
S
3
           
S
4
       

  
D
       
Pulse instruction 16-bit instruction (11-17 steps) 32-bit instruction
AH500 AH500 -
Symbol:
S
1
：
String which is replaced Word
S
2
：
New string Word
S
3
：
Number of characters in S
1
which are
replaced
Word
S
4
：
The characters in S
1
starting from the
character indicated by the value in S
4
are replaced.
Word
D
：
Device in which the execution result is
stored
Word
Explanation:
1. The characters in S
1
starting from the character indicated by the value in S
4
are replaced by
the characters in S
2
, the number of characters which are replaced is indicated by the value in
S
3
, and the result is stored in D.
2. The four characters starting from the sixth character in the string “1234567890” are replaced
by “MN”, and the result is “12345MN0”.
After the instruction
is executed
b15
b0
b7 b8
0016#
S1+1
S1+2
S1+3
16#31(1) 16#32(2)
16#33(3) 34(4)16#
36(6)16#
35(5)16#
37(7)16#
38(8)16#
39(9)16#
S1+4
b15
b0
b7 b8
0016#
16#4D(M)
4E(N)16#
S1+5
30(0)16#
4
6
16#31(1) 32(2)16#
33(3)16# 34(4)16#
4D(M)16#
35(5)16#
4E(N)16#
30(0)16#
000016#
Character which is replaced
N
umber of characters which are replaced
S1
S2
S2+1
S3
S4
D+1
D+2
D+3
D+4
D
Ignored
Ignored
3. If the string in S
2
is 16#00, the instruction has the function of deleting the characters.
4. If the value in S
3
is larger than the number of characters which can be replaced in the string in
S
1
, the characters in S
1
starting from the character indicated by the value in S
4
to the last
character in S
1
are replaced.
