Delta AH500 - Page 696

AH500 Programming Manual
6-528
Item
Code
Description
File format
2
The file name extension is .cvs.
The ASCII codes are adopted.
The value which is stored is a hexadecimal value.
3
The values are separated by a tab.
The unit of the value is the word.
The file name extension is .txt.
The ASCII codes are adopted.
The value which is stored is a hexadecimal value.
4
The values are separated by a tab.
The unit of the value is the double word.
The file name extension is .txt.
The ASCII codes are adopted.
The value which is stored is a hexadecimal value.
5
The values are not separated by any mark.
The unit of the value is the word.
The file name extension is .txt.
The ASCII codes are adopted.
The value which is stored is a hexadecimal value.
6
The values are not separated by any mark.
The unit of the value is the double word.
The file name extension is .txt.
The ASCII codes are adopted.
The value which is stored is a hexadecimal value.
Function option
0
Appending
The data which is written into the memory card is added after
the last value in the file.
Default value
If the file does not exist, it is created automatically.
1
Overwriting
The data which is written into the memory card replaces the
values in the file starting from the value indicated by the value
in S
4
.
If the file does not exist, it is created automatically.
Reserved
-
The values of bit8~bit15 are 0.
 S: The data source
 S
1
: The length of the data which is written into the file
If the value in S
1
is 0, the data is not written into the file.
Item
Description
Value unit
If the file format is 0, 1, 3, or 5, the unit of the value is the word. If
the file format is 2, 4, or 6, the unit of the value is the double word.
Parameter unit
Double word
Length of the data
The devices in which the data is stored can not exceed the device
range, and the size of the data which is written into the file can
not be more than four gigabytes.
(Please refer to chapter 2 for more information about the
devices.)
 S
2
: The line advance
The value in S
2
should be within the range between 0 and 256.
 S
3
~S
3
+4: S
3
occupies five devices. Nine characters at most constitute a file name,
including 16#00. If the string does not end with 16#00, the error occurs. If the
