4 Product overview
Scope of delivery
4. Product overview
4.1 Scope of delivery
► Check the delivery for completeness and
all components for damage before starting
installation work.
► Do not use any damaged components.
► Keep the packaging.
4.1.1 Inverter
Part Description Part Description
Inverter 1
Mounting plate 1
For mounting the inverter
Support bracket for
DC cables
6
For supporting the weight of the
DC cables
Mounting tool for DC
plug
2
For unscrewing the Amphenol H4
DC plugs from the DC connections
of the inverter
DC plug for DC+ 12
Amphenol H4 DC plug for 4/6 mm
2
(H4CF C4D●MS)
DC plug for DC– 12
Amphenol H4 DC plug for 4/6 mm
2
(H4CM C4D●MS)
Quick Installation
Guide
1
Solar-Wechselrichter
M70A_260 (Delta-Teilenummer RPI703M260000)
Deutschland Österreich SchweizBelgien
Solar-Wechselrichter
M70A_260 (Delta-Teilenummer RPI703M260000)
Installations- und Betriebsanleitung
Deutschland Österreich SchweizBelgien
Installations- und Betriebsanleitung
Allen key 1
For releasing the door screws and
securing the open door from slam-
ming shut.
