7 Installation
Mounting the inverter
Installation and Operation Manual M50A_260 RPI503M260000 Product version L and M EU V1.3 EN 2023-08-14
7.4 Mounting the inverter
7.4.1 Ground mounting (upright)
WARNING
Heavy weight
The inverter is heavy.
► Lift and carry the inverter with at least 2
people.
The feet for oor mounting must be ordered
separately.
1. Screw the 2 feet for ground mounting onto the underside
of the inverter (torque: 24.5 Nm). 4 screws, spring wash-
ers and washers are included in the scope of delivery.
2. Place the inverter vertically on the mounting surface and
screw the 2 feet onto the mounting surface.
