5 Planning the installation
Dimensions
36
Installation and Operation Manual M50A_260 RPI503M260000 Product version L and M EU V1.3 EN 2023-08-14
Sub-1G
Wi-Fi
739
731
766
80
Fig. 5.12: Inverter, dimensions with antennae (in mm)
340
310
130 75
15
12,5
60
60
458
Fig. 5.13: Feet for oor mounting. Dimensions (in mm)
