Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
Setup
h Remote ID Setup
Set remote control ID.
[Display]
1 . S p 2 . I n 3 . O p
E
O p t i o n S e t u p
E
6 R e m o t e I D 1
[Selectable items]
1
2
3
4
NOTE
When using the AVR-1508 with only the included remote control unit
(RC-1075), there is no need to make settings.
When using a separately sold remote control unit (RC-7000CI, etc.),
this function can be used. Match the ID setting of the remote control
unit and the receiver.
DTS NEO:6
: The signals are decoded in DTS NEO:6 for
playback.
Cinema
: This mode is suited for movie sources.
Music
: This mode is suited for music sources.
neural
: It is possible to play analog input signals and
PCM (2-channel, 48 kHz or less) in the surround
mode.
This is the optimum mode for playing sources
recorded in XM HD Surround (vpage 34).
Surround Playback of 2-channel Sources
DOLBY PLgx
or DOLBY PLg
: The signals are decoded in DOLBY PLgx or
DOLBY PLg for playback.
Cinema
: This mode is suited for movie sources.
Music
: This mode is suited for music sources.
Game
: This mode is suited for games.
Pro Logic
: This is the Pro Logic playback mode. This can
be selected when playing with a DOLBY PLg
decoder. When this mode is selected, “DOLBY
PL” is displayed.
Standard Playback
This is the standard mode for enjoying surround sound according
to the program source.
Surround Modes
To select these surround modes using the SELECT/ENTER knob on
the main unit or press the STD button on the remote control unit. The
mode switches each time the button is pressed.
n When using a surround back speaker
[Selectable items]
DOLBY PLgx
DTS NEO:6
neural
n When not using a surround back speaker
[Selectable items]
DOLBY PLg
DTS NEO:6
neural
Select the “Cinema”, “Music”, “Game and “Pro Logic” modes at
“Surround Parameter” – “MODE” (vpage 27).
Operations (vpage 19)

Table of Contents

Other manuals for Denon AVR-1508

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-1508 and is the answer not in the manual?

Denon AVR-1508 Specifications

General IconGeneral
HDMI Inputs2
HDMI Outputs1
Dolby DigitalYes
DTSYes
AM/FM TunerYes
Response Bandwidth10 Hz - 100 kHz
Signal-To-Noise Ratio98 dB
THD0.08%
Input Impedance47 kOhm
Input Sensitivity200 mV
Tuner TypeDigital
Preset Station Qty56
HDMI SwitchingYes
Tuning RangeFM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter24-bit / 192 kHz
Output Impedance / Channel8 Ohm
Frequency Response10 Hz - 100 kHz
Channels7.1
Power Output75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel75W (8 ohms)
