Getting Started Connections Setup Playback Multi-Zone Information Troubleshooting
ENGLISH
[MODE
SELECTOR 1]
[MODE
SELECTOR 2]
[RETURN]
[1], [2], [3],
[0], [6], [7],
[8], [9]
1
Set [MODE SELECTOR 1] to “VIDEO”.
2
Set [MODE SELECTOR 2] to the component to be
registered (SAT/CABLE or TV).
3
Press [MEMORY] and [RETURN] at the same time.
The indicator starts flashing.
4
Input the number of the component you want to set.
No.
CD 1
iPod/NETWORK 2
TAPE/CD-R/MD 3
DVD/VDP 4
VCR 5
No setting 0
[RETURN]
[MEMORY]
[NUMBER]
[Front]
[Rear]
Remote Control
Punch Through Function
“Punch Through” is a function allowing you to operate 1, 2, 3,
0, 6, 7, 8 and 9 on CD, iPod/NETWORK, TAPE/CD-R/
MD, DVD/VDP or VCR components when in the SAT/CABLE or TV
mode. By default, nothing is set.

Table of Contents

Other manuals for Denon AVR-1508

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-1508 and is the answer not in the manual?

Denon AVR-1508 Specifications

General IconGeneral
HDMI Inputs2
HDMI Outputs1
Dolby DigitalYes
DTSYes
AM/FM TunerYes
Response Bandwidth10 Hz - 100 kHz
Signal-To-Noise Ratio98 dB
THD0.08%
Input Impedance47 kOhm
Input Sensitivity200 mV
Tuner TypeDigital
Preset Station Qty56
HDMI SwitchingYes
Tuning RangeFM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter24-bit / 192 kHz
Output Impedance / Channel8 Ohm
Frequency Response10 Hz - 100 kHz
Channels7.1
Power Output75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel75W (8 ohms)
