Getting Started Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
Multi-Zone
Multi-zone Operations
Turning the Power On and Off
GOperation on the main unitH
Press <ZONE2 ON/OFF> for the zone to be operated.
GOperation on the remote control unitH
Set [MODE SELECTOR 1] to “AUDIO” and [MODE SELECTOR 2] to
“ZONE2”.
Press [ZONE2 ON] or [ZONE2 OFF].
Selecting the Input Source
GOperation on the main unitH
Press <ZONE2 / REC SELECT>, then turn <SOURCE SELECT>.
GOperation on the remote control unitH
Set [MODE SELECTOR 1] to “AUDIO” and [MODE SELECTOR 2] to
“ZONE2” .
Press [SOURCE SELECT].
Adjusting the Volume
Set [MODE SELECTOR 1] to “AUDIO” and [MODE SELECTOR 2] to
“ZONE2”.
Press [VOLUME].
– – –
–70dB
~
–40dB
~
+18dB[Variable range]
The ZONE2 volume can be adjusted only when “ZONE2” is selected
at “System Setup” – “Option Setup” – “Amp Assign” (vpage 24).
<ZONE2 ON/OFF>
<ZONE2 / REC SELECT>
SOURCE SELECT
VOLUME
[MODE
SELECTOR 1]
[MODE
SELECTOR 2]
SOURCE
SELECT
VOLUME
[MUTING]
About the button names in these explanations
< > : Buttons on the main unit
[ ] : Buttons on the remote control unit
Button name only:
Buttons on the main unit and remote control unit
Turning off the Sound Temporarily
Set [MODE SELECTOR 1] to “AUDIO” and [MODE SELECTOR 2] to
“ZONE2”.
Press [MUTING].
b To cancel, either adjust the volume or press [MUTING] again.
The setting is canceled when the zone’s power is turned off.
The source selected for ZONE2 is also output from the recording
output connectors.
NOTE
Digital audio signals input from the COAXIAL or OPTICAL connectors
cannot be played in multi-zone.
[ZONE2 ON]
SOURCE
SELECT
[ZONE2 OFF]
[Front] [Rear]
To Next Page
