[Display]
1 . S p 2 . I n 3 . O p
Q
S p e a k e r S e t u p
Q
1 F r o n t : L a r g e
Q
4 S u b w o o f e r : Y e s
s Center Speaker
Select center speaker use and size.
[Selectable items]
Large
Small
None
Select “Large” or “Small” not according to the physical size of the
speaker but according to the low frequency reproduction capabilities
based on the frequency set at “Crossover Frequency” (vpage
20).
When “Front Speaker” is set to “Small”, “Subwoofer” is
automatically set to “Yes”.
If “Subwoofer” is set to “No”, “Front Speaker” is automatically set
to “Large”.
When “Front Speaker” is set to “Small”, “Center Speaker” and
“Surround Speaker” can not be set to “Large”.
g Subwoofer Mode Setup
Select low range signal to be reproduced by subwoofer.
This can be set when “System Setup” “Speaker Setup”
“Subwoofer” is set to “Yes”.
Play music or a movie source and select the mode offering the
strongest bass.
Select “+Main” if you want the bass signals to always be produced
from the subwoofer.
[Selectable items]
Norm
: Play low range and LFE signal of channels set to “Small”.
+Main
: Play low range and LFE signal of all channels.
Large
: Select this when using large speakers with ample low
frequency reproduction capabilities.
Small
: Select this when using small speakers without ample low
frequency reproduction capabilities.
None
: Select this when no speaker is connected.
Yes
: Select this when a subwoofer is connected.
No
: Select this when no subwoofer is connected.
f Subwoofer
Select subwoofer use.
[Selectable items]
Yes
No
d Surround Speaker
Select surround speakers use and size.
[Selectable items]
Large
Small
None
a ~ f Speaker Configuration
Select speaker configuration and size.
(bass reproduction capability)
a Front Speaker
Select front speaker size.
[Selectable items]
Large
Small
For details on how to select, set and cancel settings for each menu, see “System Setup Operation” (vpage 18).
1. Speaker Setup
Use this procedure to set the speakers manually or if you wish to
change the settings made with the auto setup procedure.
a ~ f Speaker Configuration
g Subwoofer Mode Setup
h ~ A1 Distance
A2 ~ A6 Crossover Frequency
A7 Test Tone
A8 Restore
[Display]
1 . S p 2 . I n 3 . O p
Q
S p e a k e r S e t u p
Q
5 S W M o d e : N o r m
[Display]
1 . S p 2 . I n 3 . O p
Q
S p e a k e r S e t u p
Q
6 F L : 3 . 6 m
Q
1 1 S W : 3 . 6 m
h ~ A1 Distance
Set distance from listening position to speakers.
Before making the settings, measure the distance from the
listening position to the different speakers.
Distance measurement
Select the speaker you want to set, then set the distance.
Set the value closest to the measured distance.
[Variable range]
0.0m ~ 18.0m
: Settable in units of 0.1 meters.
Default setting :
FL / FR / C / SW ·············3.6 m
SL / SR ···························3.0 m
NOTE
Set the distance between the listening position and the various
speakers to no more than 6.0 meters.

