Denon AVR-1509 Owner's Manual

Last Function Memory
This stores the settings as they were directly before the standby
mode was set.
When the power is turned back on, the settings are restored to as
they were directly before the standby mode was set.
Backup Memory
The various settings are backed up for about 1 week, even if the
power is turned off or the power cord is disconnected.
Resetting the Microprocessor
Perform this procedure if the display is abnormal or if operations
cannot be performed.
When the microprocessor is reset, all the settings are reset to
their default values.
1
Turn off the power using <POWER>.
2
Press <POWER> while simultaneously pressing
<INPUT MODE> and <SPEAKERS A>.
3
Once the display starts ashing at intervals of about 1
second, release the two buttons.
If in step 3 the display does not flash at intervals of about 1 second,
start over from step 1.
Quick Select Function
With this function, the currently playing input source, volume
level, surround mode, MultEQ, Dynamic Volume, DV setting and
front speaker can be stored in the memory.
1
Set the input source, input mode, surround mode,
MultEQ and volume to the conditions you want to
store.
2
Press and hold QUICK SELECT until “Memory”
appears on the display.
The current settings will be memorized.
To call out the settings, press QUICK SELECT at which the desired
settings were stored.
Input Source Volume
Quick Select 1 DVD/HDP –40 dB
Quick Select 2 TV/CBL –40 dB
Quick Select 3 VCR –40 dB
[Quick Select Defaults]
Personal Memory Plus Function
This function sets the settings (input mode, surround mode,
MultEQ, Dynamic EQ, Dynamic Volume, audio delay etc.) last
selected for the individual input sources.
When you switch to an input source, the settings are automatically
set to the ones that were set the last time that input source was
used.
The surround parameters, tone control, MultEQ settings and the
volumes of the different speakers are stored for the individual surround
modes.

Getting Started Connections Setup Playback Remote Control Information Troubleshooting
ENGLISH
Specifications

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
