Denon AVR-1509 Owner's Manual

2. Input Setup
Use this procedure to select the input source and make the settings
related to playing input sources.
a, s HDMI In Assign
d ~ h Digital In Assign
j iPod Assign
k Audio Delay
l EXT. IN Subwoofer Level
A0 Auto Preset Memory
a, s HDMI In Assign
Select HDMI connector to assign to this source.
[Input terminals]
HDMI1 HDMI2
[Assignable input sources]
DVD/HDP
z1
TV/CBL
z2
VCR V.AUX OFF
z1 : “DVD” is displayed.
z2 : “TV” is displayed.
Input terminals
a
HDMI1
s
HDMI2
Default setting DVD/HDP TV/CBL
For details on how to select, set and cancel settings for each menu, see “System Setup Operation” (vpage 18).
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
1 H D M I 1 : D V D
W
2 H D M I 2 : T V
• With HDMI, the video and audio signals are transferred
simultaneously. (The HDMI audio signal is output from the monitor.)
At this time, set the input mode to “Auto”.
• The audio signals input from the analog, digital and EXT. IN connectors
are not output to the monitor.
d ~ h Digital In Assign
Select digital input connector to assign to this source.
[Input terminals]
COAX1 COAX2 OPT1 OPT2
[Assignable input sources]
CD AUX CDR DVD/HDP
z1
TV/CBL
z2
VCR V.AUX
OFF
z1 : “DVD” is displayed.
z2 : “TV” is displayed.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
3 C O A X 1 : D V D
W
5 O P T 1 : T V
Input terminals
d
COAXIAL1
f
COAXIAL2
g
OPTICAL1
h
OPTICAL2
Default setting DVD/HDP CD TV/CBL VCR
[Assignable input sources]
CD AUX CDR DVD/HDP
z1
TV/CBL
z2
VCR V.AUX
OFF
z1 : “DVD” is displayed.
z2 : “TV” is displayed.
With the default settings, the control dock for iPod can be used
connected to the VCR (iPod) connector.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
7 i P o d : V C R
j iPod Assign
Assign control dock for iPod to this source.
k Audio Delay
Compensate for mismatched timing between video and audio.
Delay audio.
This sets the delay time for audio signals.
[Variable range]
0 ms
~
200 ms
With a movie source, for example, adjust so that the movement of the
actors’ lips is synchronized with the sound.
Operating from the remote control unit
Press [AUDIO DELAY].
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
8 A . D e l a y : 0 m s
• This cannot be adjusted when playing in the EXT. IN, DIRECT or
STEREO mode (with “Front Speaker” set to “Large”, “Tone Control”
to “OFF” and “MultEQ” to “OFF”).
• Store each input source.
l EXT. IN Subwoofer Level
Set the subwoofer level for playback.
Select according to the player in use.
[Selectable items]
0dB +5dB +10dB
:
Select according to the player in use.
+15dB
:
This is the recommended level.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
9 E X T . I n S W : + 1 5

Getting Started Connections Setup Playback Remote Control Information Troubleshooting
ENGLISH
Specifications

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
